2-215307-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip RCP 48 POS 2.54mm Solder ST Thru-Hole
PDF
/
Inventory: 5375
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
PCB Thickness 1.6mm
Length - Tail 3.1mm
Contact Finish Thickness - Post 98.4μin 2.50μm
Contact Finish Thickness - Mating 31.5μin 0.80μm
Plating Thickness 31μin
Length 60.96mm
Height 7mm
Technical
Stackable Yes
Contact Current Rating 3A
Sealable No
Dielectric Withstanding Voltage 750VAC V
ELV Compliant
Mating Contact Pitch 0.1 inch
Insulation Resistance 5000000000Ohm
Contact Resistance 12mOhm
Lead Length 3.1mm
UL Flammability Code 94V-0
Body Breadth 0.199 inch
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number of Contacts 24
Number Of PCB Rows 2
Contact Length - Post 0.122 3.10mm
Row Spacing - Mating 0.100 (2.54mm)
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Insulation Color Green
Pitch - Mating 0.100 2.54mm
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.276 7.00mm
Depth 5.06mm
Orientation Vertical
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
HTS Code 8536.69.40.40
Additional Feature TOP ENTRY
Gender Female
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 48
Connector Type Receptacle
ECCN Code EAR99
Termination Kinked Pin, Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series AMPMODU HV-100
Published 2008
Packaging Tray
Physical
PCB Mount Retention With
Housing Material Polyester
Insulation Material Polyester, Glass Filled
Contact Shape Square
Mounting Type Through Hole
Contact Plating Tin, Gold
Contact Material Phosphor Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 8 Weeks
