87965-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Headers & Wire Housings MOD II DBL ROW RECP ASSY
PDF
/
Inventory: 6324
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Orientation Right Angle
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Row Spacing - Mating 2.54 mm
Number Of PCB Rows 2
Number of Contacts 4
PCB Contact Pattern RECTANGULAR
Contact Gender FEMALE
Housing Color Natural
Lead Length 3.68mm
Rated Current (Signal) 3A
Contact Style SQ PIN-SKT
Insulation Resistance 5000000000Ohm
ELV Compliant
Dielectric Withstanding Voltage 1050VAC V
Contact Pattern RECTANGULAR
High Temperature Compatible No
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating GOLD (50) OVER NICKEL
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Connector Type Connector, Receptacle, Socket
Termination Solder
Pbfree Code yes
JESD-609 Code e4
Dimensions
Height 6.0452mm
Plating Thickness 1.27μm
Length - Tail 3.683mm
PCB Thickness 2.36mm
Compliance
RoHS Status RoHS Compliant
Physical
PCB Mounting Orientation Right Angle
Mounting Option 1 LOCKING
Housing Material Polyphenylene
Mounting Type BOARD
Contact Plating Gold, Nickel
Contact Material Bronze
