87879-8
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
13 MODIV VRT SR OE 100/115
PDF
/
Inventory: 9040
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Gold
Mount Through Hole
Housing Material Polyester
PCB Mounting Orientation Vertical
PCB Mount Retention Without
Contact Material Bronze
Technical
JESD-609 Code e0
Pbfree Code no
Termination Solder
Connector Type Connector, Receptacle, Socket
Max Operating Temperature 125°C
Min Operating Temperature -65°C
Number of Rows 1
Additional Feature BOTTOM ENTRY, LOW PROFILE
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Current Rating 2A
Number of Conductors ONE
Reliability COMMERCIAL
Approval Agency CSA
Number Of PCB Rows 1
Number of Contacts 13
PCB Contact Pattern RECTANGULAR
Contact Gender FEMALE
UL Flammability Code 94V-0
Housing Color Black
Lead Length 2.92mm
Body Depth 0.265 inch
Rated Current (Signal) 2A
Contact Style SQ PIN-SKT
Contact Resistance 12mOhm
Insulation Resistance 5GOhm
ELV Non-Compliant
Dielectric Withstanding Voltage 750VDC V
Contact Pattern RECTANGULAR
Contact Rating (Current) 2A
Stackable Yes
High Temperature Compatible No
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Dimensions
Height 6.79mm
Plating Thickness 30μin
Contact Finish Thickness - Mating 762 nm
Length - Tail 2.921mm
PCB Thickness 1.57mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
