643426-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN HEADER 9POS VERT .250 AU
PDF
/
Inventory: 3461
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Dimensions
Width 20.3mm
Length 20.3mm
Technical
Number of Ports 1
Max Voltage Rating (AC) 600V
ELV Non-Compliant
Empty Shell NO
Lead Length 4.45mm
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 9
Row Spacing - Mating 6.35 mm
Current Rating 19A
Orientation Straight
Pitch 6.35mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Ramp
Additional Feature MATE-N-LOK, POLARIZED
Voltage - Rated 600V
Number of Rows 3
Color White
Min Operating Temperature -55°C
Max Operating Temperature 85°C
Connector Type Header, Receptacle, Socket
Termination Through Hole
Pbfree Code no
JESD-609 Code e0
Packaging Bulk
Physical
Housing Material Nylon
Shell Material POLYAMIDE
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
