5536297-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Board to Board & Mezzanine Connectors M/S 140 RA RC 125 30AU LC CB
PDF
/
Inventory: 3720
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Gold, Tin
Mount Through Hole
Housing Material Thermoplastic
PCB Mounting Orientation Right Angle
Technical
JESD-609 Code e3
Pbfree Code yes
Termination Solder
Connector Type Receptacle, Socket
Number of Positions 140
Max Operating Temperature 257°C
Min Operating Temperature -85°C
Color Natural
Number of Rows 2
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating GOLD (30) OVER NICKEL
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.2446mm
Total Number of Contacts 140
Orientation Right Angle
Number of Conductors ONE
Reliability COMMERCIAL
Row Spacing - Mating 2.54 mm
Number Of PCB Rows 5
PCB Contact Pattern RECTANGULAR
Body Breadth 0.315 inch
Contact Gender FEMALE
Body Depth 0.48 inch
Contact Style SQ PIN-SKT
Insulation Resistance 5000000000Ohm
ELV Compliant
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 500VAC V
Durability 50 Cycles
Contact Pattern RECTANGULAR
Contact Rating (Current) 10.5A
Preloaded Yes
Stackable No
Dimensions
Height 8mm
Plating Thickness 30μin
Length - Tail 3.18mm
Compliance
RoHS Status RoHS Compliant
