RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description Board to Board & Mezzanine Connectors M/S 140 RA RC 095 30AU GUIDES
PDF
/
Inventory: 9986
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Length - Tail 2.41mm
Plating Thickness 30μin
Height 8mm

Technical

Stackable No
Preloaded Yes
Contact Rating (Current) 10.5A
Contact Pattern RECTANGULAR
Durability 50 Cycles
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
ELV Compliant
Insulation Resistance 5000000000Ohm
Contact Style SQ PIN-SKT
Contact Gender FEMALE
Body Breadth 0.315 inch
PCB Contact Pattern STAGGERED
Number Of PCB Rows 5
Row Spacing - Mating 2.54 mm
Body Length or Diameter 4.4 inch
Reliability COMMERCIAL
Number of Conductors ONE
Orientation Right Angle
Total Number of Contacts 140
Pitch 1.2446mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Color Natural
Min Operating Temperature -85°C
Max Operating Temperature 257°C
Number of Positions 140
Connector Type Receptacle, Socket
Termination Solder

Physical

PCB Mounting Orientation Right Angle
Housing Material Thermoplastic
Mount Through Hole
Contact Plating Gold, Tin
Contact Material Bronze
