Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description Board to Board & Mezzanine Connectors 200,VT,RC,BD, BD,30AU,95ST
PDF
/
Inventory: 6592
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Dimensions

Stack Height 18.7452mm
Length - Tail 2.41mm
Plating Thickness 30μin
Length 130.56mm
Height 8.11mm

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free

Technical

Stackable No
Preloaded Yes
Contact Rating (Current) 10.5A
Contact Pattern RECTANGULAR
Durability 50 Cycles
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
ELV Compliant
Insulation Resistance 5000000000Ohm
Contact Style SQ PIN-SKT
PCB Contact Pattern STAGGERED
Number Of PCB Rows 5
Row Spacing - Mating 2.54 mm
Reliability COMMERCIAL
Number of Conductors ONE
Orientation Straight
Total Number of Contacts 200
Pitch 1.2446mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating GOLD (30) OVER NICKEL
Subcategory Headers and Edge Type Connectors
Gender Receptacle
Number of Rows 2
Color Natural
Min Operating Temperature -85°C
Max Operating Temperature 257°C
Number of Positions 200
Connector Type Receptacle, Socket
Termination Solder
Pbfree Code yes
JESD-609 Code e3

Physical

PCB Mounting Orientation Vertical
Housing Material Thermoplastic
Mount Through Hole
Contact Plating Gold, Tin
Contact Material Bronze
