5536255-7
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Board to Board & Mezzanine Connectors 160,VT,RC,BD,BD, 30AU,180ST
PDF
/
Inventory: 7567
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Gold, Tin
Mount Through Hole
Housing Material Thermoplastic
PCB Mounting Orientation Vertical
Technical
Termination Solder
Connector Type Receptacle, Socket
Number of Positions 160
Max Operating Temperature 257°C
Min Operating Temperature -85°C
Color Natural
Number of Rows 2
Subcategory Headers and Edge Type Connectors
Pitch 1.2446mm
Total Number of Contacts 160
Orientation Straight
Number of Conductors ONE
Reliability COMMERCIAL
Body Length or Diameter 4.14 inch
Row Spacing - Mating 2.54 mm
Number Of PCB Rows 5
PCB Contact Pattern STAGGERED
Contact Gender FEMALE
Contact Style SQ PIN-SKT
Insulation Resistance 5000000000Ohm
ELV Compliant
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 500VAC V
Durability 50 Cycles
Contact Pattern RECTANGULAR
Contact Rating (Current) 10.5A
Preloaded Yes
Stackable No
Dimensions
Height 8.11mm
Plating Thickness 30μin
Length - Termination 0.18 inch
Length - Tail 4.4958mm
Stack Height 18.7452mm
Compliance
RoHS Status RoHS Compliant
