536254-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Board to Board & Mezzanine Connectors 140 VT RC BD 30AU 125ST
PDF
/
Inventory: 5753
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Gold
Mount Through Hole
Housing Material Thermoplastic
PCB Mounting Orientation Vertical
Technical
Termination Solder
ECCN Code EAR99
Connector Type Receptacle, Socket
Number of Positions 140
Max Operating Temperature 125°C
Min Operating Temperature -65°C
Number of Rows 2
Additional Feature STAGGERED CONFIGURATION
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.27mm
Total Number of Contacts 140
Orientation Straight
Number of Conductors ONE
Reliability COMMERCIAL
Row Spacing - Mating 2.54 mm
Number Of PCB Rows 4
PCB Contact Pattern STAGGERED
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender FEMALE
Housing Color Natural
Contact Style SQ PIN-SKT
Insulation Resistance 5000000000Ohm
ELV Non-Compliant
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 500VAC V
Durability 50 Cycles
Contact Pattern RECTANGULAR
Preloaded Yes
Stackable No
Dimensions
Height 8.12mm
Length 92.46mm
Plating Thickness 30μin
Length - Tail 3.18mm
Stack Height 18.7452mm
Compliance
RoHS Status RoHS Compliant
