535676-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Headers & Wire Housings 07 MODII HORZ SR CE 100CL
PDF
/
Inventory: 5461
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Gold
Mount Through Hole
Housing Material Polyester
PCB Mounting Orientation Right Angle
Technical
Pbfree Code no
Termination Solder
Connector Type Receptacle, Socket
Max Operating Temperature -125°C
Min Operating Temperature -55°C
Color Black
Number of Rows 1
Additional Feature AMPMODU
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Right Angle
Current Rating 2A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Approval Agency CSA, UL
Number Of PCB Rows 2
Number of Contacts 7
PCB Contact Pattern RECTANGULAR
Contact Gender FEMALE
UL Flammability Code 94V-0
Lead Length 2.92mm
Body Depth 0.32 inch
Rated Current (Signal) 2A
Contact Style SQ PIN-SKT
Insulation Resistance 5000000000Ohm
ELV Non-Compliant
Durability 200 Cycles
Contact Pattern RECTANGULAR
High Temperature Compatible Yes
Dimensions
Plating Thickness 30μin
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
