5-87961-5
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Headers & Wire Housings 112 MODII HORZ DR CE 100CL/115
PDF
/
Inventory: 9953
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
PCB Thickness 1.57mm
Length - Tail 2.8956mm
Length - Termination 0.115 inch
Plating Thickness 1.27μm
Height 6.0452mm
Technical
High Temperature Compatible No
Contact Pattern RECTANGULAR
PCB Contact Row Spacing 7.874 mm
Dielectric Withstanding Voltage 1050VAC V
ELV Compliant
Insulation Resistance 5000000000Ohm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Lead Length 2.92mm
Housing Color Natural
Contact Gender FEMALE
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Body Length or Diameter 5.64 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Orientation Right Angle
Total Number of Contacts 112
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature STACKABLE
Number of Rows 2
Number of Positions 112
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination Solder
Pbfree Code yes
Physical
PCB Mounting Orientation Right Angle
Mounting Option 1 LOCKING
Housing Material Polyphenylene
Mounting Type BOARD
Contact Plating Gold
Contact Material Bronze
