5-174639-0
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Board to Board & Mezzanine Connectors 1.25FP R20 DL B N BG
PDF
/
Inventory: 6302
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Contact Pattern RECTANGULAR
Durability 30 Cycles
PCB Contact Row Spacing 3.9878 mm
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
ELV Compliant
Body/Shell Style PLUG
Insulation Resistance 100000000Ohm
Contact Style SQ PIN-SKT
Rated Current (Signal) 0.5A
Body Depth 0.138 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -30°C
Contact Gender FEMALE
Body Breadth 0.157 inch
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Number of Contacts 20
Number Of PCB Rows 2
Row Spacing - Mating 1.2446 mm
Body Length or Diameter 0.549 inch
Reliability COMMERCIAL
Number of Conductors ONE
Pitch 1.2446mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature LOOSE PIECE
Number of Rows 2
Color Black
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Pbfree Code yes
Packaging Bulk
Physical
Insulation Material POLYPHENYLENE SULPHIDE
Mount Surface Mount
Contact Plating Tin
Contact Material Bronze
