5-174638-0
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
LOOSE PIECE Rectangular Connector Header
PDF
/
Inventory: 9939
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Tin
Mount Surface Mount
Insulation Material POLYPHENYLENE SULPHIDE
Technical
Packaging Bulk
JESD-609 Code e3
Pbfree Code yes
Termination Solder
ECCN Code EAR99
Connector Type Receptacle
Color Black
Number of Rows 1
Additional Feature LOOSE PIECE
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.2446mm
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 1
Number of Contacts 20
PCB Contact Pattern RECTANGULAR
Contact Gender FEMALE
Operating Temperature (Min) -30°C
UL Flammability Code 94V-0
Rated Current (Signal) 0.5A
Insulation Resistance 500000000Ohm
ELV Compliant
Polarization Key HOUSING SIDE
Dielectric Withstanding Voltage 500VDC V
Contact Pattern RECTANGULAR
Dimensions
Plating Thickness 30μin
Compliance
Radiation Hardening No
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
