Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description Rectangular Connector Female Socket
PDF
/
Inventory: 7233
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

PCB Thickness 3.18mm
Length - Tail 4.45mm
Length - Termination 0.175 inch
Plating Thickness 1.27μm
Height 6.0452mm

Technical

High Temperature Compatible No
Contact Pattern RECTANGULAR
PCB Contact Row Spacing 7.874 mm
ELV Compliant
Body/Shell Style PLUG
Contact Style SQ PIN-SKT
Lead Length 4.445mm
Contact Gender Female
PCB Contact Pattern RECTANGULAR
Number of Contacts 80
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Body Length or Diameter 4.04 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Orientation Right Angle
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Color Natural
Connector Type Connector, Receptacle, Socket
Termination Solder
Pbfree Code yes
Packaging Bulk

Physical

PCB Mounting Orientation Right Angle
Housing Material Polyphenylene
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
