281349-2 image
Favorite
281349-2 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description Conn Socket Strip SKT 8 POS 2.54mm Solder ST Thru-Hole
PDF
/
Inventory: 1654
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Bronze
Contact Plating Gold
Mounting Type BOARD
Housing Material Thermoplastic
Mounting Style STRAIGHT
PCB Mounting Orientation Vertical

Technical

JESD-609 Code e4
Pbfree Code yes
Termination Solder
ECCN Code EAR99
Connector Type Connector, Receptacle, Socket
Number of Rows 1
Gender Female
Additional Feature AMPMODU
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Number Of PCB Rows 1
Number of Contacts 8
PCB Contact Pattern RECTANGULAR
UL Flammability Code 94V-0
Housing Color Black
Lead Length 3.5mm
Body Depth 0.343 inch
Rated Current (Signal) 3A
Contact Style SQ PIN-SKT
Insulation Resistance 5GOhm
ELV Compliant
Dielectric Withstanding Voltage 750VAC V
Contact Pattern RECTANGULAR
Contact Rating (Current) 3A
Stackable Yes
High Temperature Compatible No

Dimensions

Height 8.7122mm

Compliance

RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
