RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description Headers & Wire Housings 16 POS .100 DR MODU
PDF
/
Inventory: 1237
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Dimensions

Length - Termination 0.138 inch
Plating Thickness 15μin

Technical

High Temperature Compatible No
Stackable Yes
Insertion Force-Max 1.668 N
Contact Pattern RECTANGULAR
Durability 100 Cycles
Dielectric Withstanding Voltage 750VAC V
ELV Compliant
Insulation Resistance 1000000000Ohm
Contact Style SQ PIN-SKT
Body Depth 0.343 inch
Lead Length 3.5mm
UL Flammability Code 94V-0
Contact Gender FEMALE
PCB Contact Pattern RECTANGULAR
Number of Contacts 16
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Orientation Right Angle
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature AMPMODU
Number of Rows 2
Color Black
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Pbfree Code yes
JESD-609 Code e4
Packaging Bulk

Physical

PCB Mounting Orientation Right Angle
Housing Material Thermoplastic
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
