215306-7
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip RCP 7 POS 2.54mm Solder ST Thru-Hole
PDF
/
Inventory: 1519
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Tin
Mounting Type BOARD
Housing Material Polyester
Mounting Style STRAIGHT
PCB Mounting Orientation Vertical
Technical
Pbfree Code yes
Termination Solder
ECCN Code EAR99
Connector Type BOARD CONNECTOR
Number of Rows 1
Gender Female
Additional Feature AMPMODU
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 1
Number of Contacts 7
PCB Contact Pattern RECTANGULAR
Body Breadth 0.099 inch
Operating Temperature (Min) -65°C
UL Flammability Code 94V-0
Housing Color Green
Lead Length 3.1mm
Body Depth 0.244 inch
Rated Current (Signal) 3A
Contact Style BELLOWED TYPE
Insulation Resistance 5000000000Ohm
Body/Shell Style RECEPTACLE
ELV Compliant
Contact Pattern RECTANGULAR
Stackable Yes
Dimensions
Plating Thickness 98μin
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
