2-87964-9
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Receptacle
PDF
/
Buying Options
Total Price: USD $283.67
Unit Price: USD $283.669113
≥1 USD $283.669113
≥210 USD $113.186422
≥510 USD $109.403957
≥990 USD $107.534387
Inventory: 6299
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
PCB Thickness 2.36mm
Length - Tail 3.683mm
Length - Termination 0.115 inch
Plating Thickness 1.27μm
Height 6.0452mm
Technical
High Temperature Compatible No
Contact Pattern RECTANGULAR
PCB Contact Row Spacing 7.874 mm
Dielectric Withstanding Voltage 1050VAC V
ELV Compliant
Insulation Resistance 5000000000Ohm
Contact Resistance 12mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Lead Length 3.68mm
Housing Color Natural
PCB Contact Pattern RECTANGULAR
Number of Contacts 60
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Body Length or Diameter 3.04 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Depth 8.13mm
Orientation Right Angle
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Gender Female
Number of Rows 2
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination Solder
Pbfree Code yes
Physical
PCB Mounting Orientation Right Angle
Mounting Option 1 LOCKING
Housing Material Polyphenylene
Mounting Type BOARD
Contact Plating Gold
Contact Material Bronze
