2-87962-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Headers & Wire Housings 46 MODII HORZ DR CE 100CL/115
PDF
/
Inventory: 6986
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
PCB Thickness 1.57mm
Length - Tail 2.92mm
Plating Thickness 1.27μm
Length 59.44mm
Height 6.0452mm
Technical
High Temperature Compatible No
Contact Pattern RECTANGULAR
PCB Contact Row Spacing 7.874 mm
Dielectric Withstanding Voltage 1050VAC V
ELV Compliant
Insulation Resistance 5000000000Ohm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Lead Length 2.92mm
Housing Color Natural
UL Flammability Code 94V-0
PCB Contact Pattern RECTANGULAR
Number of Contacts 46
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Depth 8.13mm
Orientation Right Angle
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature AMPMODU, RECEPTACLE
Gender Female
Number of Rows 2
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination Solder
Pbfree Code yes
Physical
PCB Mounting Orientation Right Angle
Mounting Option 1 LOCKING
Housing Material Polyphenylene
Mounting Type BOARD
Contact Plating Nickel, Gold
Contact Material Bronze
