2-216604-3
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Headers & Wire Housings HV190 REC ASSY 2X23P.
PDF
/
Inventory: 1835
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Material Bronze
Contact Plating Gold, Tin
Mount Through Hole
Contact Shape Square
Housing Material Polyester
PCB Mounting Orientation Right Angle
PCB Mount Retention Without
Technical
Packaging Bulk
JESD-609 Code e3
Pbfree Code yes
Termination Solder
ECCN Code EAR99
Connector Type Connector, Receptacle, Socket
Max Operating Temperature 125°C
Min Operating Temperature -65°C
Color Green
Number of Rows 2
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Right Angle
Depth 7.62mm
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Row Spacing - Mating 7.62 mm
Number Of PCB Rows 2
Number of Contacts 23
PCB Contact Pattern RECTANGULAR
Contact Gender FEMALE
UL Flammability Code 94V-0
Lead Length 3.2mm
Rated Current (Signal) 3A
Contact Style BELLOWED TYPE
Contact Resistance 12mOhm
Insulation Resistance 5000000000Ohm
Body/Shell Style PLUG
ELV Compliant
Plating Gold
Dielectric Withstanding Voltage 750VAC V
Contact Pattern RECTANGULAR
Sealable No
Contact Rating (Current) 3A
Stackable Yes
Dimensions
Height 5.7912mm
Length 58.42mm
Plating Thickness 2.5μm
Contact Finish Thickness - Mating 762 nm
Length - Tail 3.2mm
PCB Thickness 1.6mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
