2-173145-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Board to Board & Mezzanine Connectors STACK REC ASSY 34P
PDF
/
Inventory: 4287
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Plating Thickness 8μm
Length 45.7mm
Height 7.62mm
Stack Height 18.9992mm
PCB Thickness 1.6mm
Length - Tail 17mm
Contact Finish Thickness - Mating 8μm
Technical
Stackable Yes
Contact Rating (Current) 1.5A
Contact Pattern RECTANGULAR
Polarization Key POLARIZED HOUSING
ELV Compliant
Insulation Resistance 5GOhm
Contact Style SQ PIN-SKT
Lead Length 16.9926mm
UL Flammability Code 94V-0
Contact Gender FEMALE
Body Breadth 0.3 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number of Contacts 34
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Approval Agency CSA
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 3A
Depth 7.6mm
Orientation Straight
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature ACTION PIN
Number of Rows 2
Color Black
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination Through Hole
Pbfree Code yes
JESD-609 Code e3
Packaging Bulk
Physical
PCB Mount Retention With
Housing Material PBT
Contact Shape Square
Mount Through Hole
Contact Plating Gold
Contact Material COPPER ALLOY
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
