2-102278-4
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Headers & Wire Housings MOD II DBL ROW RECP ASSY
PDF
/
Inventory: 2179
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Contact Material Bronze
Contact Plating Nickel, Gold
Mount Through Hole
Housing Material Polyphenylene
PCB Mounting Orientation Right Angle
PCB Mount Retention Without
Technical
Pbfree Code yes
Termination Solder
ECCN Code EAR99
Connector Type Connector, Receptacle, Socket
Max Operating Temperature 105°C
Min Operating Temperature -65°C
Number of Rows 2
Gender Female
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Right Angle
Depth 8.13mm
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Row Spacing - Mating 2.54 mm
Number Of PCB Rows 2
Number of Contacts 50
PCB Contact Pattern RECTANGULAR
UL Flammability Code 94V-0
Housing Color Natural
Lead Length 4.445mm
Contact Style SQ PIN-SKT
Contact Resistance 12mOhm
Body/Shell Style PLUG
ELV Compliant
Plating Gold
PCB Contact Row Spacing 7.874 mm
Contact Pattern RECTANGULAR
Stackable No
Dimensions
Height 6.0452mm
Length 64.52mm
Plating Thickness 1.27μm
Contact Finish Thickness - Mating 1.27μm
Length - Tail 4.45mm
PCB Thickness 1.57mm
Compliance
RoHS Status RoHS Compliant
