1674000-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Header
PDF
/
Inventory: 6707
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 200 nm
Plating Thickness 200 nm
Length 10.8mm
Height 3.25mm
Technical
Contact Rating (Current) 1A
Contact Pattern RECTANGULAR
Wire/Cable Gauge 28 AWG
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
ELV Compliant
Body/Shell Style PLUG
Insulation Resistance 500000000Ohm
Contact Style SQ PIN-SKT
Rated Current (Signal) 1A
Operating Supply Voltage 10V
PCB Contact Pattern RECTANGULAR
Number of Contacts 8
Number Of PCB Rows 2
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 1A
Pitch 990.6μm
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Gender Female
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Header, Receptacle, Socket
ECCN Code EAR99
Termination SMD/SMT
Pbfree Code yes
Packaging Tape & Reel
Physical
PCB Mount Alignment Without
PCB Mounting Orientation Vertical
Housing Material Nylon
Mount Surface Mount
Contact Plating Gold
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
