Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description Rectangular Connector Header
PDF
/
Inventory: 6355
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Min Operating Temperature -65°C
Number of Rows 1
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Current Rating 2A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Approval Agency CSA, UL
Number Of PCB Rows 1
Number of Contacts 9
PCB Contact Pattern RECTANGULAR
Contact Gender FEMALE
Housing Color Black
Lead Length 2.92mm
Body Depth 0.34 inch
Rated Current (Signal) 3A
Contact Style SQ PIN-SKT
Body/Shell Style RECEPTACLE
ELV Non-Compliant
Dielectric Withstanding Voltage 750VAC V
Durability 75 Cycles
Contact Pattern RECTANGULAR
Withdrawl Force-Min .2085 N
Stackable Yes
Max Operating Temperature -105°C
Connector Type BOARD CONNECTOR
Termination Solder
Pbfree Code no
JESD-609 Code e0
High Temperature Compatible No

Physical

PCB Mounting Orientation Vertical
Mounting Style STRAIGHT
Housing Material Polyester
Mounting Type BOARD
Contact Plating Gold
Contact Material Bronze

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
