146139-4
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
AMPMODU Rectangular Connector Receptacle
PDF
/
Inventory: 7181
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Gold
Mounting Type BOARD
Housing Material Polyester
Mounting Option 1 LOCKING
PCB Mounting Orientation Right Angle
Technical
Termination Solder
Connector Type BOARD CONNECTOR
Max Operating Temperature -125°C
Min Operating Temperature -55°C
Number of Rows 1
Additional Feature AMPMODU
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Right Angle
Current Rating 2A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Approval Agency CSA, UL
Number Of PCB Rows 2
Number of Contacts 5
PCB Contact Pattern RECTANGULAR
Contact Gender FEMALE
UL Flammability Code 94V-0
Housing Color Black
Lead Length 2.92mm
Body Depth 0.32 inch
Rated Current (Signal) 2A
Contact Style SQ PIN-SKT
Body/Shell Style RECEPTACLE
ELV Non-Compliant
PCB Contact Row Spacing 7.874 mm
Contact Pattern RECTANGULAR
Withdrawl Force-Min 3.336 N
High Temperature Compatible Yes
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
