1-173145-4
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Board to Board & Mezzanine Connectors RCPT 50P DUAL STACKING
PDF
/
Inventory: 1636
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Straight
Depth 7.6mm
Current Rating 3A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Approval Agency CSA
Row Spacing - Mating 2.54 mm
Number Of PCB Rows 2
Number of Contacts 50
PCB Contact Pattern RECTANGULAR
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.3 inch
Contact Gender FEMALE
UL Flammability Code 94V-0
Lead Length 16.9926mm
Contact Style SQ PIN-SKT
Insulation Resistance 5GOhm
ELV Compliant
Polarization Key POLARIZED HOUSING
Contact Pattern RECTANGULAR
Contact Rating (Current) 1.5A
Stackable Yes
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature ACTION PIN
Number of Rows 2
Color Black
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination Through Hole
Pbfree Code yes
JESD-609 Code e3
Packaging Bulk
Dimensions
Height 7.62mm
Length 66mm
Plating Thickness 8μm
Contact Finish Thickness - Mating 8μm
Length - Tail 17mm
PCB Thickness 1.6mm
Stack Height 18.9992mm
Physical
PCB Mount Retention With
Housing Material PBT
Contact Shape Square
Mount Through Hole
Contact Plating Gold
Contact Material COPPER ALLOY
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
