1-102986-0
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Receptacle
PDF
/
Inventory: 5621
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 23.57mm
Technical
High Temperature Compatible No
ELV Non-Compliant
Contact Resistance 12mOhm
Lead Length 2.92mm
Housing Color Black
Number of Contacts 27
Approval Agency CSA
Depth 14.6mm
Orientation Right Angle
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Female
Number of Rows 3
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Termination Solder
Physical
PCB Mounting Orientation Right Angle
Housing Material Thermoplastic
Mounting Type BOARD
Contact Plating Gold
Contact Material Bronze
