531138-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Receptacle
PDF
/
Inventory: 6340
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper
Contact Plating Gold
Mount Through Hole
Housing Material Polyphenylene
Technical
JESD-609 Code e0
Pbfree Code no
Termination Through Hole
ECCN Code EAR99
Connector Type Connector, Receptacle, Socket
Number of Positions 105
Color Brown
Number of Rows 3
Subcategory Headers and Edge Type Connectors
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Total Number of Contacts 105
Orientation Vertical
Number of Conductors ONE
Reliability COMMERCIAL
Body Length or Diameter 4.25 inch
Number Of PCB Rows 3
PCB Contact Pattern RECTANGULAR
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.495 inch
Contact Gender Female
Lead Length 4.95mm
Body Depth 0.45 inch
Contact Style SQ PIN-SKT
ELV Compliant
Polarization Key ENDS
Contact Pattern RECTANGULAR
Mating Contact Row Spacing 0.1 inch
Dimensions
Length - Termination 0.195 inch
Compliance
RoHS Status Non-RoHS Compliant
