530778-4
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular MIL Spec Connectors 2 ROW BOX RECP 60 POS 100 C/L
PDF
/
Inventory: 7232
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Length - Termination 0.405 inch
Technical
Mating Contact Row Spacing 0.1 inch
Contact Pattern RECTANGULAR
Polarization Key ENDS
Termination Type WIRE WRAP
ELV Compliant
Contact Style SQ PIN-SKT
Body Depth 0.4 inch
Lead Length 10.29mm
Contact Gender FEMALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Body Length or Diameter 3.855 inch
Reliability COMMERCIAL
Number of Conductors ONE
Military Standard MIL-DTL-55302
Orientation Vertical
Total Number of Contacts 60
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 2
Color Blue
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Pbfree Code yes
Physical
Contact Shape Square
Number of Pins 60
Mount Through Hole
Contact Plating Gold
Contact Material Copper
