TLE-120-01-G-DV-A-K-TR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip SKT 40 POS 2mm Solder ST SMD T/R
PDF
/
Buying Options
Total Price: USD $5.97
Unit Price: USD $5.9664
≥1 USD $5.9664
≥10 USD $5.5176
≥100 USD $5.2096
≥500 USD $5.0248
≥1000 USD $3.7224
Inventory: 448
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Length 40mm
Technical
Row Spacing - Mating 0.079 (2.00mm)
Insulation Color Black
Pitch - Mating 0.079 2.00mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.177 4.50mm
Depth 4mm
Orientation Straight
Total Number of Contacts 40
Current Rating (Amps) 3.2A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Push-Pull
Gender Female
Number of Rows 2
Number of Positions 40
Connector Type Receptacle, Pass Through
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide, Pick and Place
JESD-609 Code e4
Series TLE
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Housing Material Polymer
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Contact Material Phosphor Bronze
