SSW-126-01-F-D-LL-002
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Female Socket
PDF
/
Inventory: 5899
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2013
Series SSW
Part Status Active
Termination Kinked Pin, Solder
Connector Type Receptacle
Number of Positions 52
Number of Rows 2
Gender Female
Fastening Type Push-Pull
Voltage - Rated DC 655V
Contact Finish - Mating Gold
Contact Type Forked
Current Rating (Amps) 5.7A per Contact
Insulation Height 0.335 8.51mm
Style Board to Board or Cable
Number of Positions Loaded 51
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Voltage - Rated AC 465V
Row Spacing - Mating 0.100 (2.54mm)
Contact Length - Post 0.104 2.64mm
Lead Pitch 2.54mm
Contact Finish - Post Tin
Lead Length 2.64mm
Dimensions
Contact Finish Thickness - Mating 3.00μin 0.076μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Lead Free Lead Free
