SSW-124-02-G-S-RA-LL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip SKT 24 POS 2.54mm Solder RA Thru-Hole
PDF
/
Inventory: 7202
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole, Right Angle
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2013
Series SSW
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Termination Kinked Pin, Solder
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 24
Number of Rows 1
Gender Female
HTS Code 8536.69.40.40
Fastening Type Push-Pull
Subcategory Headers and Edge Type Connectors
Voltage - Rated DC 655V
Contact Finish - Mating Gold
Contact Type Forked
Current Rating (Amps) 5.7A per Contact
Insulation Height 0.095 2.41mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Number of Conductors ONE
Reference Standard UL, CSA
Voltage - Rated AC 465V
Reliability COMMERCIAL
Body Length or Diameter 2.42 inch
Contact Length - Post 0.100 2.54mm
Number Of PCB Rows 1
Lead Pitch 2.54mm
PCB Contact Pattern RECTANGULAR
Body Breadth 0.095 inch
Lead Length 2.54mm
Body Depth 0.335 inch
Dimensions
Plating Thickness 20μin
Contact Finish Thickness - Mating 20.0μin 0.51μm
Contact Finish Thickness - Post 3.00μin 0.076μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Lead Free Lead Free
