SSW-113-01-T-D-011
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Header
PDF
/
Inventory: 1716
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Technical
Lead Length 2.64mm
Lead Pitch 2.54mm
Contact Length - Post 0.104 2.64mm
Row Spacing - Mating 0.100 (2.54mm)
Voltage - Rated AC 465V
Insulation Color Black
Pitch - Mating 0.100 2.54mm
Number of Positions Loaded 25
Style Board to Board or Cable
Insulation Height 0.335 8.51mm
Current Rating (Amps) 5.7A per Contact
Contact Type Forked
Contact Finish - Mating Tin
Voltage - Rated DC 655V
Fastening Type Push-Pull
HTS Code 8536.69.40.40
Gender Female
Number of Rows 2
Number of Positions 26
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Part Status Active
JESD-609 Code e3
Series SSW
Published 2013
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
