SSW-112-03-T-D-RA-012
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RCPT 24POS 0.1 TIN PCB R/A
PDF
/
Inventory: 5445
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole, Right Angle
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Series SSW
Part Status Active
Termination Solder
Connector Type Receptacle
Number of Positions 24
Number of Rows 2
Additional Feature POLARIZED
Fastening Type Push-Pull
Voltage - Rated DC 655V
Contact Finish - Mating Tin
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Forked
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 5.7A per Contact
Insulation Height 0.195 4.95mm
Style Board to Board or Cable
Number of Positions Loaded 23
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Voltage - Rated AC 465V
Row Spacing - Mating 0.100 (2.54mm)
Contact Length - Post 0.300 7.62mm
Lead Pitch 2.54mm
Contact Gender FEMALE
UL Flammability Code 94V-0
Lead Length 7.62mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Lead Free Lead Free
