SSW-112-01-T-D-LL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip SKT 24 POS 2.54mm Solder ST Thru-Hole
PDF
/
Inventory: 8747
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Length 30.99mm
Technical
Durability 100 Cycles
Polarization Key POLARIZED HOUSING
Max Current Rating 6.9A
Max Voltage Rating (AC) 550V
Contact Resistance 10mOhm
Lead Length 2.64mm
Housing Color Black
Body Breadth 0.195 inch
PCB Contact Pattern RECTANGULAR
Lead Pitch 2.54mm
Number Of PCB Rows 2
Contact Length - Post 0.104 2.64mm
Row Spacing - Mating 0.100 (2.54mm)
Reliability COMMERCIAL
Voltage - Rated AC 465V
Reference Standard UL, CSA
Number of Conductors ONE
Pitch - Mating 0.100 2.54mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.335 8.51mm
Depth 4.95mm
Orientation Straight
Current Rating (Amps) 5.7A per Contact
Contact Type Forked
Contact Finish - Mating Tin
Voltage - Rated DC 655V
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
HTS Code 8536.69.40.40
Gender Female
Number of Rows 2
Number of Positions 24
Connector Type Receptacle
ECCN Code EAR99
Termination Kinked Pin, Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SSW
Published 2016
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Mounting Option 1 LOCKING
Housing Material Polymer
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 6 Weeks
