SSW-109-02-G-Q-RA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip SKT 18 POS 2.54mm Solder RA Thru-Hole Tube
PDF
/
Buying Options
Total Price: USD $4.87
Unit Price: USD $4.871722
≥1 USD $4.871722
≥10 USD $4.595957
≥100 USD $4.335812
≥500 USD $4.090395
≥1000 USD $3.858855
Inventory: 9663
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole, Right Angle
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Housing Material Polymer
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series SSW
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Termination Solder
Connector Type Receptacle
Number of Positions 27
Number of Rows 3
Gender Female
Additional Feature TIGER BUY CONTACT
Fastening Type Push-Pull
Subcategory Headers and Edge Type Connectors
Voltage - Rated DC 655V
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Forked
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 5.7A per Contact
Orientation Right Angle
Depth 15.11mm
Insulation Height 0.295 7.50mm
Style Board to Board or Cable
Number of Positions Loaded 18
Pitch - Mating 0.100 2.54mm
Number of Conductors ONE
Reference Standard UL, CSA
Voltage - Rated AC 465V
Reliability COMMERCIAL
Row Spacing - Mating 0.100 (2.54mm)
Contact Length - Post 0.100 2.54mm
Number Of PCB Rows 2
Lead Pitch 2.54mm
PCB Contact Pattern RECTANGULAR
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.295 inch
UL Flammability Code 94V-0
Housing Color Black
Lead Length 2.54mm
Contact Resistance 10mOhm
Mating Contact Pitch 0.1 inch
Max Voltage Rating (AC) 550V
Max Current Rating 6.9A
PCB Contact Row Spacing 5.08 mm
Dimensions
Length 23.37mm
Plating Thickness 20μin
Contact Finish Thickness - Mating 20.0μin 0.51μm
Contact Finish Thickness - Post 3.00μin 0.076μm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
