SSW-106-02-G-D-LL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Female Socket
PDF
/
Inventory: 6493
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Housing Material Polymer
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2013
Series SSW
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Kinked Pin, Solder
Connector Type Receptacle
Number of Positions 12
Number of Rows 2
Gender Female
Fastening Type Push-Pull
Voltage - Rated DC 655V
Contact Finish - Mating Gold
Contact Type Forked
Current Rating (Amps) 5.7A per Contact
Orientation Straight
Depth 4.95mm
Insulation Height 0.335 8.51mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Voltage - Rated AC 465V
Row Spacing - Mating 0.100 (2.54mm)
Contact Length - Post 0.194 4.93mm
Lead Pitch 2.54mm
Housing Color Black
Contact Resistance 10mOhm
Max Voltage Rating (AC) 550V
Max Current Rating 6.9A
Dimensions
Length 15.75mm
Contact Finish Thickness - Mating 20.0μin 0.51μm
Contact Finish Thickness - Post 3.00μin 0.076μm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
