SSW-101-24-S-T
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
SSW ROHS3Compliant COMMERCIAL UL CSA Connector Receptacle 100Cycles 10mOhm -55C~125C 5.7A per Contact
PDF
/
Inventory: 7684
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series SSW
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Termination Solder
Connector Type Receptacle
Number of Positions 3
Number of Rows 3
Gender Female
Fastening Type Push-Pull
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Forked
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 5.7A per Contact
Pitch 2.54mm
Insulation Height 0.335 8.51mm
Style Board to Board or Cable
Number of Positions Loaded All
Insulation Color Black
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Body Length or Diameter 0.12 inch
Row Spacing - Mating 0.100 (2.54mm)
Contact Length - Post 0.584 14.83mm
Number Of PCB Rows 3
Contact Finish - Post Tin
PCB Contact Pattern RECTANGULAR
Body Breadth 0.295 inch
UL Flammability Code 94V-0
Contact Resistance 10mOhm
Polarization Key POLARIZED HOUSING
Durability 100 Cycles
Dimensions
Contact Finish Thickness - Mating 30.0μin 0.76μm
Length - Termination 0.584 inch
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status ROHS3 Compliant
