SSQ-104-02-L-Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RCPT 12POS 0.1 GOLD PCB
PDF
/
Inventory: 2446
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Technical
Contact Gender FEMALE
Contact Finish - Post Tin
Contact Length - Post 0.194 4.93mm
Row Spacing - Mating 0.100 (2.54mm)
Voltage - Rated AC 465V
Insulation Color Black
Pitch - Mating 0.100 2.54mm
Number of Positions Loaded 8
Style Board to Board or Cable
Insulation Height 0.335 8.51mm
Terminal Pitch 2.54mm
Current Rating (Amps) 6.3A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Forked
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Voltage - Rated DC 655V
Fastening Type Push-Pull
Additional Feature TIGER BUY CONTACT
Number of Rows 3
Number of Positions 12
Connector Type Receptacle
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SSQ
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
