SSM-108-L-DV-BE-A-M
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
SSM ROHS3Compliant 2016 GENERAL PURPOSE Connector Receptacle, Bottom Entry -55C~125C 5.2A per Contact 405VAC 572VDC 10.0muin 0.25mum
PDF
/
Buying Options
Total Price: USD $13.19
Unit Price: USD $13.185455
≥1 USD $13.185455
≥196 USD $5.262103
≥504 USD $5.086175
≥1008 USD $4.999523
Inventory: 9768
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2016
Series SSM
JESD-609 Code e3
Feature Board Guide, Pick and Place
Pbfree Code yes
Part Status Active
Termination Solder
Connector Type Receptacle, Bottom Entry
Number of Positions 16
Number of Rows 2
Gender Female
Voltage - Rated 405VAC 572VDC
Fastening Type Push-Pull
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 5.2A per Contact
Total Number of Contacts 16
Insulation Height 0.290 7.37mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Row Spacing - Mating 0.100 (2.54mm)
Contact Finish - Post Tin
UL Flammability Code 94V-0
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Compliance
RoHS Status ROHS3 Compliant
