SSM-103-L-SV
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RCPT .100" 3POS SNGL VERT
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8272
≥1 USD $0.8272
≥10 USD $0.6952
≥100 USD $0.62436
≥500 USD $0.510875
≥1000 USD $0.454115
≥3000 USD $0.397346
Inventory: 953
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Housing Material Polymer
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2000
Series SSM
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Termination Solder
Connector Type Receptacle, Pass Through
Number of Positions 3
Number of Rows 1
Gender Receptacle
Voltage - Rated 405VAC 572VDC
Additional Feature E.L.P., TIGER CLAW
Fastening Type Push-Pull
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 5.2A per Contact
Total Number of Contacts 3
Orientation Vertical
Depth 2.54mm
Insulation Height 0.290 7.37mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Number Of PCB Rows 2
Contact Finish - Post Tin
PCB Contact Pattern STAGGERED
UL Flammability Code 94V-0
Housing Color Black
Contact Resistance 10mOhm
Max Voltage Rating (AC) 475V
Max Current Rating 6.9A
Dimensions
Length 7.62mm
Width 2.54mm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
