SS-112-G-2-N

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description Rectangular Connector Female Socket
PDF
/
Buying Options
Total Price: USD $3.51
Unit Price: USD $3.510685
≥1 USD $3.510685
≥10 USD $3.311975
≥100 USD $3.124503
≥500 USD $2.947641
≥1000 USD $2.780798
Inventory: 1100
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Contact Finish Thickness - Post 10.0μin 0.25μm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Width 2.54mm
Length 30.5mm
Height 3.3mm

Technical

Device Socket Type IC SOCKET
Housing Color Black
PCB Contact Pattern RECTANGULAR
Number of Contacts 12
Contact Length - Post 0.125 3.18mm
Pitch - Mating 0.100 2.54mm
Current Rating 1A
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.300 7.62mm
Contact Type Female Socket
Contact Finish - Mating Gold
Fastening Type Push-Pull
HTS Code 8536.69.40.40
Gender Female
Number of Rows 1
Number of Positions 12
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
JESD-609 Code e4
Series SS
Published 2008
Packaging Tube
Operating Temperature -55°C~125°C

Physical

Housing Material Plastic
Insulation Material Polybutylene Terephthalate (PBT), Glass Filled
Contact Shape Circular
Mounting Type Through Hole
Mount Through Hole
Contact Material Beryllium Copper
