SQW-162-01-S-5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Header
PDF
/
Buying Options
Total Price: USD $162.49
Unit Price: USD $162.488443
≥1 USD $162.488443
≥200 USD $64.834941
≥500 USD $62.667343
≥1000 USD $61.597329
Inventory: 5637
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 30.0μin 0.76μm
Technical
Contact Finish - Post Tin
Contact Length - Post 0.090 2.29mm
Row Spacing - Mating 0.079 (2.00mm)
Insulation Color Black
Pitch - Mating 0.079 2.00mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.250 6.35mm
Current Rating (Amps) 3.8A per Contact
Contact Type Forked
Contact Finish - Mating Gold
Fastening Type Push-Pull
Gender Female
Number of Rows 5
Number of Positions 310
Connector Type Receptacle
Termination Solder
Part Status Active
Series SQW
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
