SQW-122-01-F-D-VS
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip SKT 44 POS 2mm Solder ST SMD Tube
PDF
/
Buying Options
Total Price: USD $19.97
Unit Price: USD $19.973148
≥1 USD $19.973148
≥200 USD $7.969303
≥500 USD $7.704097
≥1000 USD $7.571494
Inventory: 6744
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 3.00μin 0.076μm
Plating Thickness FLASH inch
Technical
Insertion Force-Max .5004 N
Durability 100 Cycles
Polarization Key POLARIZED HOUSING
Mating Contact Pitch 0.079 inch
Contact Resistance 10mOhm
UL Flammability Code 94V-0
Body Breadth 0.157 inch
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number Of PCB Rows 2
Row Spacing - Mating 0.079 (2.00mm)
Body Length or Diameter 1.743 inch
Reliability COMMERCIAL
Voltage - Rated AC 500V
Reference Standard UL, CSA
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.079 2.00mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.300 7.62mm
Total Number of Contacts 44
Current Rating (Amps) 3.8A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Forked
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
HTS Code 8536.69.40.40
Additional Feature FLEXYZ, TIGER BUY CONTACT
Gender Female
Number of Rows 2
Number of Positions 44
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SQW
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Mounting Option 1 LOCKING
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
