SQT-150-03-L-5-001
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip SKT 250 POS 2mm Solder ST Thru-Hole
PDF
/
Inventory: 2515
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Technical
Lead Length 6.28mm
UL Flammability Code 94V-0
Contact Finish - Post Tin
Contact Length - Post 0.208 5.28mm
Row Spacing - Mating 0.079 (2.00mm)
Voltage - Rated AC 450V
Insulation Color Black
Pitch - Mating 0.079 2.00mm
Number of Positions Loaded 249
Style Board to Board or Cable
Insulation Height 0.250 6.35mm
Terminal Pitch 2mm
Current Rating (Amps) 5.1A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Forked
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Push-Pull
Additional Feature POLARIZED
Voltage - Rated 450VAC
Gender Female
Number of Rows 5
Number of Positions 250
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Part Status Active
Series SQT
Published 2016
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
