SQT-127-02-L-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RCPT 27POS 0.079 GOLD PCB
PDF
/
Inventory: 3033
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Mounting Option 1 LOCKING
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series SQT
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Termination Solder
Connector Type Receptacle
Number of Positions 27
Number of Rows 1
Voltage - Rated 450VAC
Additional Feature FLEXYZ, TIGER BUY CONTACT
Fastening Type Push-Pull
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Forked
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 5.1A per Contact
Terminal Pitch 2mm
Insulation Height 0.250 6.35mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.079 2.00mm
Insulation Color Black
Number of Conductors ONE
Reference Standard UL, CSA
Voltage - Rated AC 450V
Reliability COMMERCIAL
Contact Length - Post 0.600 15.24mm
Number Of PCB Rows 1
Contact Finish - Post Tin
PCB Contact Pattern RECTANGULAR
Body Breadth 0.079 inch
Contact Gender FEMALE
Lead Length 15.24mm
Body Depth 0.25 inch
Mating Contact Pitch 0.079 inch
Polarization Key POLARIZED HOUSING
Withdrawl Force-Min .834 N
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Length - Termination 0.6 inch
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Lead Free Lead Free
