SQT-107-01-L-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RCPT 2MM 7POS SGL VERT PCB
PDF
/
Buying Options
Total Price: USD $2.11
Unit Price: USD $2.111469
≥1 USD $2.111469
≥10 USD $1.991946
≥100 USD $1.879204
≥500 USD $1.772826
≥1000 USD $1.67248
Inventory: 3225
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Width 2mm
Length 14.3mm
Technical
Withdrawl Force-Min .834 N
Polarization Key POLARIZED HOUSING
Max Current Rating 5.5A
Max Voltage Rating (AC) 450V
Contact Resistance 10mOhm
Lead Length 2.29mm
Housing Color Black
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Lead Pitch 2mm
Number Of PCB Rows 1
Contact Length - Post 0.090 2.29mm
Reliability COMMERCIAL
Voltage - Rated AC 450V
Reference Standard UL, CSA
Number of Conductors ONE
Pitch - Mating 0.079 2.00mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.250 6.35mm
Depth 2mm
Orientation Straight
Current Rating (Amps) 5.1A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Forked
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
Additional Feature FLEXYZ, TIGER BUY CONTACT
Voltage - Rated 450VAC
Gender Female
Number of Rows 1
Number of Positions 7
Connector Type Receptacle
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SQT
Published 2015
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Housing Material Polymer
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
