SMM-117-02-S-D
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
SAMTEC SMM-117-02-S-D Board-To-Board Connector, SMM Series, 34 Contacts, Receptacle, 2 mm, Surface Mount, 2 Rows
PDF
/
Buying Options
Total Price: USD $10.37
Unit Price: USD $10.370436
≥1 USD $10.370436
≥10 USD $9.783435
≥100 USD $9.229653
≥500 USD $8.707215
≥1000 USD $8.214362
Inventory: 5102
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 30.0μin 0.76μm
Plating Thickness 30μin
Width 4mm
Length 34mm
Technical
Withdrawl Force-Min .417 N
PCB Contact Row Spacing 4.5466 mm
Max Current Rating 3.9A
Max Voltage Rating (AC) 350V
Mating Contact Pitch 0.079 inch
Contact Resistance 10mOhm
Housing Color Black
Body Breadth 0.158 inch
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Lead Pitch 2mm
Number Of PCB Rows 2
Row Spacing - Mating 0.079 (2.00mm)
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Pitch - Mating 0.079 2.00mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.140 3.56mm
Depth 4mm
Orientation Straight
Total Number of Contacts 34
Current Rating (Amps) 3.2A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
HTS Code 8536.69.40.40
Additional Feature ELP, TIGER EYE
Voltage - Rated 350VAC
Number of Rows 2
Number of Positions 34
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Tiger Eye? SMM
Published 2000
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Housing Material Polymer
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 1 Weeks
