SMM-112-02-L-S-LC-09
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
POLARIZED STAGGERED CONFIGURATION Rectangular Connector Receptacle
PDF
/
Inventory: 8247
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type Surface Mount
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Series Tiger Eye? SMM
Feature Board Lock
Part Status Active
Termination Solder
Connector Type Receptacle
Number of Positions 12
Number of Rows 1
Voltage - Rated 350VAC
Additional Feature POLARIZED, STAGGERED CONFIGURATION
Fastening Type Push-Pull
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 3.2A per Contact
Total Number of Contacts 11
Terminal Pitch 2mm
Insulation Height 0.140 3.56mm
Style Board to Board or Cable
Number of Positions Loaded 11
Reach Compliance Code compliant
Pitch - Mating 0.079 2.00mm
Insulation Color Black
Contact Finish - Post Tin
UL Flammability Code 94V-0
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Compliance
Material Flammability Rating UL94 V-0
