SMM-111-02-S-S-03
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip SKT 11 POS 2mm Solder ST SMD Automotive Tube
PDF
/
Inventory: 6180
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 30.0μin 0.76μm
Length 22mm
Technical
Max Current Rating 3.9A
Max Voltage Rating (AC) 350V
Contact Resistance 10mOhm
Contact Finish - Post Tin
Insulation Color Black
Pitch - Mating 0.079 2.00mm
Number of Positions Loaded 10
Style Board to Board or Cable
Insulation Height 0.140 3.56mm
Depth 2mm
Orientation Straight
Current Rating (Amps) 3.2A per Contact
Contact Type Female Socket
Contact Finish - Mating Gold
Fastening Type Push-Pull
HTS Code 8536.69.40.40
Voltage - Rated 350VAC
Gender Female
Number of Rows 1
Number of Positions 11
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Tiger Eye? SMM
Published 2016
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Housing Material Polymer
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 3 Weeks
